Stereo System: What Do I Have?
I recently bought a second-hand 2015 Mini One with Visual Boost (6.5" center screen). I know I have 6 speakers - 1 under each front seat, 1 in each door and 1 in each rear side.
The sound just doesn't quite cut it - not after my 2006 Cooper anyway - so I'm looking into some upgrades.
For example one place offered me the following options:
Thanks in advance.
The sound just doesn't quite cut it - not after my 2006 Cooper anyway - so I'm looking into some upgrades.
For example one place offered me the following options:
- First (cheapest) Option: Replace the door speakers with 2-way speakers, which they said wouldn't do much.
- Next Option: Replace the door speakers and add an amp to bump up the 8" speakers under the seats.
- Next Option: Component speakers up front, Alpine amp, and Alpine sub.
Thanks in advance.
#3
Plug your vin into http://bimmer.work/
But it doesn't give the details, such as speaker sizes or brands, that I'm looking for.
#4
#5
Do you have the speakers in the A-pillars?
https://www.ecstuning.com/Mini-2014-...20A/ES2917909/
If you do, that's the Harmon Kardon, otherwise you have the base system.
I have the HK, it's mostly adequate.
See the build thread...
https://www.northamericanmotoring.co...dio-build.html
There was a page at Harmon Kardon that had more detail.
http://www.harmankardon.com/content?ContentID=mini
Here's a page from RealOEM with current part numbers, not sure how to translate that to specs.
http://www.realoem.com/bmw/enUS/part...i-Cooper&mg=65
https://www.ecstuning.com/Mini-2014-...20A/ES2917909/
If you do, that's the Harmon Kardon, otherwise you have the base system.
I have the HK, it's mostly adequate.
See the build thread...
https://www.northamericanmotoring.co...dio-build.html
There was a page at Harmon Kardon that had more detail.
http://www.harmankardon.com/content?ContentID=mini
Here's a page from RealOEM with current part numbers, not sure how to translate that to specs.
http://www.realoem.com/bmw/enUS/part...i-Cooper&mg=65
Last edited by hammerhands; 04-06-2016 at 12:40 AM.
#6
+1 thats a great way to tell and very easy.
__________________
MINI Guru/ MINI Owner Since 2004 | NEW Lifetime Part Replacement | Local Pickup
Milltek | Genuine MINI | Forge Motorsport | NM Engineering | ECS Performance | M7 Speed
Customer Service Hours: 8am-8pm EST|Sales Team Hours: 8am-11pm | SAT 10am-7pm 800.924.5172
MINI Guru/ MINI Owner Since 2004 | NEW Lifetime Part Replacement | Local Pickup
Milltek | Genuine MINI | Forge Motorsport | NM Engineering | ECS Performance | M7 Speed
Customer Service Hours: 8am-8pm EST|Sales Team Hours: 8am-11pm | SAT 10am-7pm 800.924.5172
#7
Thanks all, but...
- Mini.the.Moocher: I went to both sites and they just don't give enough detail.
- hammerhands: Please see my original post. I wrote that I only have 6 speakers, no HK and no tweeters in the A pillars. Hence, I have the base system.
For example, when a place tells me that they can put 2-ways in the doors - how do I know that I don't already have 2-ways? Or they can put 8" woofers under the seats - what if I already have 8" under the seats?
Thanks again.
- Mini.the.Moocher: I went to both sites and they just don't give enough detail.
- hammerhands: Please see my original post. I wrote that I only have 6 speakers, no HK and no tweeters in the A pillars. Hence, I have the base system.
For example, when a place tells me that they can put 2-ways in the doors - how do I know that I don't already have 2-ways? Or they can put 8" woofers under the seats - what if I already have 8" under the seats?
Thanks again.
Trending Topics
#8
You may be able to jam bigger speakers in there, see what other people have done.
If you look at the Realoem link, you can see that the mid-range speakers are the same size in both systems and the woofer units seem to be similar in size. The HK website says the mid-range speakers in the HK system are 100mm, and the woofers are 217mm.
Those must be full-range speakers in the base system, they are handling both high and mid.
You probably have a spot to mount the center speakers the HK has. Do you have the cutouts and covers for the tweeters in the rear? The tweeters are 26mm in the HK system.
Those A-pillars with the tweeter pods are not too expensive.
If you look around on the Realoem site you will see how they mount the amplifier.
Go to a MINI dealer and see if you like the HK system.
Picture from realoem showing front door speakers.
1. is base system speaker.
2. is HK system speaker.
If you look at the Realoem link, you can see that the mid-range speakers are the same size in both systems and the woofer units seem to be similar in size. The HK website says the mid-range speakers in the HK system are 100mm, and the woofers are 217mm.
Those must be full-range speakers in the base system, they are handling both high and mid.
You probably have a spot to mount the center speakers the HK has. Do you have the cutouts and covers for the tweeters in the rear? The tweeters are 26mm in the HK system.
Those A-pillars with the tweeter pods are not too expensive.
If you look around on the Realoem site you will see how they mount the amplifier.
Go to a MINI dealer and see if you like the HK system.
Picture from realoem showing front door speakers.
1. is base system speaker.
2. is HK system speaker.
Last edited by hammerhands; 04-06-2016 at 01:35 AM.
